| Technical Data |
| Operating voltage | 12 - 15 V/DC stabilized (max. 0,1 A)
| | Temperature range | approx. 0 - 100°C
| | Switching output | relay contact 1 x switch-over, max. 5 A, 25 V
| | The sensor (Ø 5 mm) may be connected with the control electronics via a cable with a length of up to 1 m
| | Dimensions | ca. 60 x 45 x 25 mm (without fastening straps) |
Adjustable electronic temperature switch. The sensor (Ø 5 mm) may be connected with the control electronics via a cable with a length of up to 1 m.
|
