| Technical Data |
| Operating voltage | 6 - 16 V/DC
| | Current consumption | max. 800 mA
| | Input sensitivity | < 80 mV
| | Loudspeaker connection | 4 - 16 ohm
| | Music power | max. 12 W with 16 V at a 4 ohm loudspeaker
| | Frequency response | approx. 40 - 20000 Hz
| | Dimensions | approx. 62 x 36 x 23 mm (without fixing straps) |
Robust amplifier module for universal use. The module is cast humidity-proof and shake-proof. The casting compound and the module case consist of a special, highly heat-conductive plastic. So no additional heat sinks are needed. The module is protected electronically against overheating and overload.
Please notice the article "Mini-Kraftpaket" from the german magazine "Electronic Actuell Magazin" no. 3/99.
Available accessory: M040 - Universal preamplifier
|
