| Technical Data |
| Input voltage | 6 - 28 V/DC
| | Output voltage adjustable | 3 - 15 V/DC (electronically stabilized)
| | Note | The input voltage must be at least 3 V higher than the adjusted output voltage
| | Max. output current | 1,5 A
| | Max. dissipation | approx. 3 W without heat sink, approx. 10 W with heat sink (not enclosed)
| | Dimensions | approx. 60 x 45 x 20 mm (without fastening straps) |
Input: 6 - 28 V/DC output: 3 - 15 V/DC
The input voltage must be at least 3 V higher than the adjusted output voltage. The adjusted output voltage is stabilized or short circuit-proof. For operation of appliances with lower voltages at a 12 V or 24 V car battery or power supplies.
|
